Medical gas supply can be found in medical institutions and most other medical facilities.
Essential medical gases used by various departments are supplied
through gas pipes which contains
N2
In all types of operations, pneumatic surgical instruments are generally driven by nitrogen, supplied by high-pressure gas cylinders.
Gas pressure maintained at approximately 1.2 MPa (175 psi) for space requirements.
Gas Distribution System (GDS) is monitored by the central or system-specific alarm.
The overall gas pipeline system design plan also covers the corresponding control cabinet and monitoring design to effectively enhance remote control and operational efficiency, and to control risks and hazards arising from external gas leakage. The operation shall be carried out according to the clean room operation mode of each science and technology factory.
Oxygen is used through oxygen masks in patients who need oxygen supplementation.
In general, large liquid oxygen tanks in hospitals are the source of oxygen storage and centralized supply. Liquid oxygen is evaporated into gaseous oxygen through a vacuum adiabatic evaporator (VIE) at a pressure of about 345-380 kPa (50-55 psi) or 4-5 bar in Europe.-5 bar。In small medical centers with fewer patients, oxygen is usually supplied through groups of high-pressure oxygen cylinders.
Oxygen can also be produced through oxygen manufacturing machines if the above centralized supply and high pressure oxygen cylinders are not feasible.
However, the production of oxygen on the ground is still quite new technology.
Water volume: V10L
Pressure resistance: TP250 kg/cm2
Maximum filling pressure: FP 150 kg/cm2
Size: 14cm in diameter, 90cm in height
Gas analysis method: According to European Pharmacopoeia
Cylinder inspection method: According to CNS 1261.Z1001 safety regulations for high pressure oxygen cylinders
Contains medical oxygen: Department of Health Drugs No. 055023
Water volume: V3.4L
Pressure resistance: TP250 kg/cm2
Maximum filling pressure: FP 150 kg/cm2
Size: 10cm diameter, 63.5cm height
Gas analysis method: According to European Pharmacopoeia
Cylinder inspection method: According to CNS 1261.Z1001 safety regulations for high pressure oxygen cylinders
Contains medical oxygen: Department of Health Drugs No. 055023
Water volume: V2.6L
Pressure resistance: TP250 kg/cm2
Maximum filling pressure: FP 150 kg/cm2
Size: 11.4cm diameter, 49.4cm height
Gas analysis method: according to European Pharmacopoeia
Cylinder inspection method: According to CNS 1261.Z1001 safety regulations for high pressure oxygen cylinders
Contains medical oxygen: Department of Health Drugs No. 055023
Medical pressure regulator
Type: B358-A
Flow rate: 1-15 L/min
Import Specification: W22*14RH
Export specifications: O2 DISS
With oxygen humidifier bottle and nasal cannula set
【下一個國家隊！ 政府點名防護衣、氧氣機】
影片來源 東森財經新聞
醫療氧氣相關許可證
Medical Oxygen Specification and Time Comparison Table
3.4L 110mins=1h50mins
10L 277mins=4h37mins
The above data are the results of the actual test using our FU Type: B358-A Oxygen Regulator for reference only.
